SGPE F500 triplex drilling mud pump
Horizontal single-acting triplex mud pump for drilling-fluid circulation on land rigs, offshore units and workover rigs. SGPE’s F500 model is part of the API 7K F500–F2200 series and is specified with 370 kW / 500 HP rated power.
Process Industry · Power Generation · EQUIPMENT
API 7K F500
PRICE & AVAILABILITY
Send us your part number, model or specifications. Our team will confirm the exact reference, price and availability before quoting.
Technical specifications
| Brand | SGPE |
|---|---|
| Category | EQUIPMENT |
| Industry | Process Industry · Power Generation |
| Pump type | Horizontal reciprocating single-acting triplex piston |
| Rated power | 370 kW / 500 HP |
| Rated speed | 165 SPM |
| Stroke | 191 mm / 7-1/2 in |
| Maximum liner | 6-3/4 in |
| Maximum reference displacement | 575 GPM / 2177 L/min |
| Maximum reference pressure | 26.3 MPa / 3800 psi |
| Gear ratio | 4.29:1 |
| Typical suction connection | 8 in |
| Typical discharge connection | 4-1/16 in |
| Valve configuration | API No. 5 valve |
| Supply forms | Bare pump, skid-mounted unit or complete package |
Summary datasheet — SGPE API 7K F500
The SGPE F500 is a horizontal, reciprocating, single-acting triplex piston drilling mud pump. It is intended to move drilling fluid under high pressure from the mud system through the drill string and bit nozzles, supporting hole cleaning, bit cooling and wellbore stability.
Within SGPE’s F-Series, the F500 is specified at 370 kW / 500 HP, 165 SPM, a 191 mm / 7-1/2 in stroke, a 6-3/4 in maximum liner and a 26.3 MPa / 3800 psi maximum reference pressure. The source states that these figures are reference values and that final configuration depends on liner size, fluid end, drive arrangement and project conditions.
Typical applications listed include land drilling rigs, offshore units, workover service, shallow wells, auxiliary circulation, directional drilling and rig upgrades. SGPE also describes supply options such as bare pumps, skid-mounted units, electric or diesel drives and compatible spare packages including liners, pistons, valves, seats, rods and fluid ends.
